ASTM A320 Grade L7 Stud Bolts
G41400
A320 Grade L7 Stud Bolts are manufactured from 4140 Alloy Steel in accordance with ASTM A320 specification. Torqbolt is a prominent A320 Grade L7 Stud Boltsupplier in India.
Related Products
42Crmo4 Bolts Astm A193 Grade B7 Stud Bolts Astm A193 Grade B7M Bolts Astm A194 Grade 7 Hex Nuts Astm A194 Grade 7M Hex Nuts Astm A320 Grade L7 Bolts Astm A320 Grade L70 Stud Bolts Astm A320 Grade L7M Stud Bolts
ASTM A320 Grade L7 Stud Bolts Properties
ASTM A320 Grade L7 Stud Bolts Chemical Requirements
Ferritic Steels
| Grade Symbol | Description | C | Mn | P, max | S, max | Si | Ni | Cr | Mo | B | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ASTM A320 L7 | Cr - Mo - B | Range,% | 0.38 - 0.48C | 0.75 - 1.00 | 0.035 | 0.04 | 0.15 - 0.35 | ... | 0.80 - 1.10 | 0.15 - 0.25 | ... |
| Product Variation, % Over or Under | 0.02 | 0.04 | 0.005 over | 0.005 over | 0.02 | ... | 0.05 | 0.02 | ... | ||
ASTM A320 Grade L7 Stud Bolts Mechanical Requirements
Ferritic Steels
| Class and Grade, Diameter, in. [mm] | Heat Treatment | Minimum Tempering Temperature, °F [°C] | Tensile Strength, min, ksi [MPa] | Yield Strength, min, ksi [MPa] (0.2 % offset) | Elongation in 2 in. or 50 mm, min, % | Reduction of Area, min, % | Hardness, max |
|---|---|---|---|---|---|---|---|
| ASTM A320 L7 21/2[65] and underA | quenched and tempered | 1100 [593] | 125[860] | 105[725] | 16 | 50 | 321 HBW or 35 HRC |
ASTM A320/A320M Impact Test Requirements
| Grade | Test Temperature | CVN Specimen Section Size, mm | Min Average Impact Toughness of Three Test Specimens, ft-lbf [J] | Min Impact Value of a Single Specimen of Set of Three, ft-lbf [J] | |
|---|---|---|---|---|---|
| °F | °C | ||||
| ASTM A320 L7 | - 150 | - 101 | 10 × 7.5 | 16 [22] | 12 [16] |
| 10 × 10 | 40 [54] | 30 [41] | |||
