ASTM A193 Grade B8R Stud Bolts
1.4311, 304LN, S30451, X2CRNIN18-10
ASTM A193 Grade B8R Bolts are manufactured from 305 Stainless Steel in accordance with ASTM A193 specification. Torqbolt is a prominent A193 gr B8R bolt supplier in India.
Related Products
Astm A193 Grade B8R Class 2 Bolts Astm A193 Grade B8Ra Bolts Astm A194 Grade 8R Heavy Hex Nuts A194 Grade 8Ra Nuts Nitronic 60 Stainless Steel Springs Nitronic 60 Bolts Nitronic 60 Fasteners Nitronic 60 Forgings Alloy 218 Nuts Nitronic 60 Screws Nitronic 60 Stud Bolts Nitronic 60 Stainless Steel Washers 1.4565 Studs
ASTM A193 Grade B8R Stud Bolts Properties
ASTM A193 Grade B8R Stud Bolts Chemical Requirements
Austenitic Steels
| Grade | Description and UNS Designatio | Classes | C | Mn | P | S | Si | Cr | Ni | Mo | Cu | CbF | Ti | V | N |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ASTM A193 Grade B8R | S20910 | 1C, 1D | 0.06 | 4.0-6.0 | 0.045 | 0.030 | 1.00 | 20.5-23.5 | 11.5-13.5 | 1.50-3.00 | . . . | 0.10-0.30 | . . . | 0.10-0.30 | 0.20-0.40 |
| Product Analysis VariationB | 0.01 | 0.05 | 0.005 | 0.005 | 0.05 | 0.25 | 0.15 | 0.10 | . . . | 0.05 | . . . | 0.02 | 0.02 |
ASTM A193 Grade B8R Stud Bolts Mechanical Requirements
Austenitic Steels (Inch)
| Grade | Diameter, in. |
Heat TreatmentB | Tensile Strength, min, ksi |
Yield Strength, min, 0.2 % offset, ks |
Elongation in 4 D,min | Reduction of Area, min | Hardness, max |
|---|---|---|---|---|---|---|---|
| ASTM A193 Grade B8R Classes 1C and 1D | All diameters | carbide solution treated | 100 | 55 | 35 | 55 | 271 HBW or 28 HRC |
Austenitic Steels (Metric)
| Grade Class , mm |
Diameter | Heat TreatmentB | Tensile Strength, min,MPa |
Yield Strength, min, 0.2 % offset, MPa |
Elongation in 4 D,min % | Reduction of Area, min % | Hardness, max |
|---|---|---|---|---|---|---|---|
| ASTM A193M Grade B8R All diameters Classes 1C and 1D | All diameters | carbide solution treated | 690 | 380 | 35 | 55 | 271 HBW or 28 HRC |
